Intel® Xeon® Processor E5-2697 v4

US$ 10869.02
Agregar al Carrito
Intel® Xeon® Processor E5-2697 v4
Favoritos Consultar

Essentials

Performance

  • # of Cores18
  • # of Threads36
  • Processor Base Frequency2.30 GHz
  • Max Turbo Frequency3.60 GHz
  • Cache45 MB SmartCache
  • Bus Speed9.6 GT/s QPI
  • # of QPI Links2
  • TDP145 W
  • VID Voltage Range0

Supplemental Information

  • Embedded Options AvailableNo
  • DatasheetView now

Memory Specifications

  • Max Memory Size (dependent on memory type)1.5 TB
  • Memory TypesDDR4 1600/1866/2133/2400
  • Max # of Memory Channels4
  • Max Memory Bandwidth76.8 GB/s
  • Physical Address Extensions46-bit
  • ECC Memory Supported Yes

Expansion Options

  • Scalability2S
  • PCI Express Revision3.0
  • PCI Express Configurations x4, x8, x16
  • Max # of PCI Express Lanes40

Package Specifications

  • Sockets SupportedFCLGA2011-3
  • Max CPU Configuration2
  • TCASE79°C
  • Package Size45mm x 52.5mm
  • Low Halogen Options AvailableNo

Advanced Technologies

  • Intel® Turbo Boost Technology 2.0
  • Intel® vPro™ Platform Eligibility Yes
  • Intel® Hyper-Threading Technology Yes
  • Intel® Virtualization Technology (VT-x) Yes
  • Intel® Virtualization Technology for Directed I/O (VT-d)Yes
  • Intel® VT-x with Extended Page Tables (EPT) Yes
  • Intel® TSX-NIYes
  • Intel® 64 Yes
  • Instruction Set64-bit
  • Instruction Set ExtensionsIntel® AVX2
  • Idle StatesYes
  • Enhanced Intel SpeedStep® TechnologyYes
  • Intel® Demand Based SwitchingYes
  • Thermal Monitoring TechnologiesYes
  • Intel® Flex Memory AccessNo
  • Intel® Identity Protection Technology No

Security & Reliability

  • Intel® AES New InstructionsYes
  • Secure KeyYes
  • Intel® OS GuardYes
  • Intel® Trusted Execution Technology Yes
  • Execute Disable Bit Yes
Socalo de CPU : 2011
Tipo de Memoria : DDR4 RDIMM
Cache : 45MB
Cores : 18
Frequencia : 2.3G
Marca : INTEL
Memoria RAM maxima : 1.5TB
Threads : 36
