Main Specifications | |||||||||||||||||||||||||||
Chipset | Broadcom BCM57414 | ||||||||||||||||||||||||||
Device type | Ethernet Controller | ||||||||||||||||||||||||||
Dimensions (WxDxH) | 5.6” x 2.713” (14.224 x 6.89cm) | ||||||||||||||||||||||||||
Form Factor | Low-Profile, Short Length Standard | ||||||||||||||||||||||||||
Interface (Bus) Type | PCI-E 3.0 x8 (8GT/s, 5GT/s or 2.5GT/s) interface | ||||||||||||||||||||||||||
Weight | 90.5g (0.2lb) | ||||||||||||||||||||||||||
Networking | |||||||||||||||||||||||||||
Features | Jumbo frames (up to 9600-Byte) | ||||||||||||||||||||||||||
802.3x flow control | |||||||||||||||||||||||||||
Link Aggregation (802.3ad) | |||||||||||||||||||||||||||
Virtual LANs- 802.1q VLAN tagging | |||||||||||||||||||||||||||
Configurable Flow Acceleration | |||||||||||||||||||||||||||
IEEE 1588 and Time Sync | |||||||||||||||||||||||||||
Management Features | Network Controller Sideband Interface (NC-SI) | ||||||||||||||||||||||||||
PXE v2.1 remote boot | |||||||||||||||||||||||||||
Asset Management with Thermal Sensors | |||||||||||||||||||||||||||
Port Quantity | Dual SFP28 connectors - 25Gb/port | ||||||||||||||||||||||||||
Virtualization Features | NetQueue, VMQueue, and Multiqueue | ||||||||||||||||||||||||||
Support for 128 Virtual Functions | |||||||||||||||||||||||||||
VXLAN, NVGRE, Geneve | |||||||||||||||||||||||||||
Edge Virtual Bridging (EVB) | |||||||||||||||||||||||||||
Power | |||||||||||||||||||||||||||
Comsumtion Operational | Typical power consumption: 5.2W | ||||||||||||||||||||||||||
Environmental Parameters | |||||||||||||||||||||||||||
Operating Temperature | Operating temperature: 0°C to 55°C (32°F to 131°F) | ||||||||||||||||||||||||||
Storage temperature: -40°C to 70°C (-40°F to 158°F) | |||||||||||||||||||||||||||
Storage humidity: 90% non-condensing relative humidity at 35°C | |||||||||||||||||||||||||||
Miscellaneous | |||||||||||||||||||||||||||
Compliance Standards | RoHS Compliant 6/6, Pb Free | ||||||||||||||||||||||||||
Compatible Motherboards and Servers | Al MBs with a PCI-E x8 slot | ||||||||||||||||||||||||||
All servers with a PCIE x8 slot |
Interfaz : | PCI-E |
Marca : | SUPERMICRO |
Puertos : | 2 x SPF+ |
Velocidad : | 25 GBPS |
