SIOM Dual-port 25GbE SFP28 ports Intel Fortville-25 XXV710

US$ 853.30
Agregar al Carrito
AOC-M25G-I2S-O • Super I/O Module (SIOM) Form Factor • Intel® XXV710 25GbE controller, Dual SFP28 connectors • Network Virtualization: VXLAN and NVGRE • Intel® Ethernet Flow Director for hardware-based application ? traffic steering • Data Plane Development Kit (DPDK) optimized for efficient ? packet processing • NC-SI for Remote Management • Asset Management Features
Favoritos Consultar

• General
  - Super I/O Module (SIOM) Form Factor
  - Intel® XXV710 25GbE controller
  - Dual SFP28 connectors with speed up to 25Gbps per port
  - Time Sync (IEEE1588)

• I/O Features
  - Intel® Ethernet Flow Director
  - Intel® XXV710 25GbE controller
  - MSI-X support
  - Multiple queues: 1,536 Tx and Rx queues per port
  - Tx/Rx IP, SCTP, TCP, and UDP checksum offloading
  ? (IPv4, IPv6) capabilities

• Virtualization Features
  - Next-Generation VMDq with up to 256 VMDq VMs supported
  - SR-IOV
  - Virtual Machine Load Balancing (VMLB)
  - VLAN support
  - VXLAN and NVGRE support

• Management Features
  - Preboot eXecution Environment (PXE) support
  - iSCSI boot
  - Asset Management features with thermal sensor
  - NC-SI for remote management

• Advanced Software Features
  - Teaming support
  - IEEE 802.3ad (link aggregation control protocol)
  - IEEE 802.1Q VLANs
  - IEEE 802.3 2005 flow control support
  - IEEE 802.1p
  - Receive Side Scaling

• Operation System Support
  - Windows Server 2008 R2 / 2012 / 20012 R2 / 2016
  - Linux Stable Kernel version 2.6/4.x
  - Linux RHEL 6.9 / 7.3
  - Linux SLES 11 SP4 / 12 SP1
  - FreeBSD 10.3 / 11
  - UEFI 2.1 / 2.3 / 2.4
  - VMware vSphere 5.1 / 5.5
  - VMware ESXi 6.0 U3 / 6.0

• Power Consumption
  - Maximum 11.8W

• Operating Conditions
  - Operating temperature: 0°C to 55°C (32°F to 131°F)
  - Storage temperature: -40°C to 70°C (-40°F to 158°F)
  - Storage humidity: 90% non-condensing relative humidity
  ? at 35°C

• Physical Dimensions
  - Card PCB dimensions: 92mm (3.62in) x 87.1mm (3.43in)
  ? (W x D)

Interfaz : SIOM
Marca : SUPERMICRO
Puertos : 2 x SPF+
