2U chassis support for SMCI Proprietary WIO motherboards; max. motherboard size - 12" x 13", 13" x 13.68"
* Support up to 12"x13" MB with rear 2.5" HDD option installed
12x 3.5" Hot-swap SAS3/SATA Drive Bays and Optional 2x 2.5" Hot-swap SATA3 Drive Bays for OS mirroring
*SAS or enterprise SATA HDD only recommended
Backplane
SAS3 Dual Expander Backplane features:
• Up to 12Gbps support
• In-band SES-2 Enclosure Management Support
• SAS3/SATA3 support
• 8x Mini-SAS HD connectors
• Scalability through cascading
• Redundancy support through SAS drive only
Front Panel
Buttons
• Power On/Off button
• System Reset button
System Cooling
Fans
3x 80mm 7K RPM Chassis middle fan w/ housing
System Monitoring
Chassis intrusion switch
Operating Environment (System)
Operating Temperature Range
10 - 35°C (50° - 95°F)
Non-Operating Temperature Range
-40 - 60°C (-40° - 140°F)
Humidity Range
8 - 90% non-condensing
Non-Operating Humidity Range
5 - 95% non-condensing
Power Supply with Power Distributor
920W high-efficiency (94+%) power supply with PMBus
