CSE-826BAC4-R1K23WB

US$ 4604.32
Agregar al Carrito
CSE-826BAC4-R1K23WB
Favoritos Consultar

Product SKUs

CSE-826BAC4-R1K23WB
  • SuperChassis 826BAC4-R1K23WB

Form Factor

  • 2U chassis support for SMC Proprietary WIO motherboards max. motherboard size - 12" x 13", 13" x 13.68".
  • Support up to 12"x13" MB with rear 2.5" HDD option installed

Processor Support

  • Dual and Single Intel® and AMD processors

Dimensions

Height
  • 3.5" (89 mm)
Width
  • 17.2" (437 mm)
Depth
  • 25.5" (647 mm)
Net Weight
  • 40 lbs (18.14 kg)
Gross Weight
  • 55 lbs (24.95 kg)
Packaging (W x H x L)
  • 26.7" (678 mm) x 11.4" (290 mm) x 34.5" (876 mm)
Available Color
  • Black

Expansion Slots

  • WIO Slots (4x Full-height, Half-length + 3x Low-profile)

Drive Bays

  • 12 x 3.5" hot-swap drive bay
  • Optional 2 x 2.5" hot-swap drive bay
  • 8x SAS3 12Gbps and 4x Hybrid (NVMe/SAS3) 3.5" HDD

Backplane

  • 12-port 2U SAS3 12Gbps hybrid backplane, support up to 8x 3.5-inch SAS3/SATA3 HDD/SSD and 4x SAS3/SATA3/NVMe Storage Devices

Front Panel

Buttons
  • Power On/Off button
  • System Reset Button
LEDs
  • 2 Network Activity LEDs
  • Fan Fail/System Over Heat LED
  • HDD activity LED
  • Power Status LED
  • Unit Identification (UID) LED
Systems Cooling

Fans
  • 3 x 8cm high-performance PWM fan(s)
  • Optional 5 x 6cm 4pin high performance fan(s)

System Monitoring

  • Chassis intrusion switch

Operating Environment (System)

Operating Temperature Range
  • 5°C - 35°C (41°F - 95°F)
Non-Operating Temperature Range
  • -40°C - 70°C (-40°F - 158°F)
Operating Relative Humidity Range
  • 8% - 90% (non-condensing)
Non-Operating Relative Humidity Range
  • 5% - 95% (non-condensing)

Power Supply
1U 1200W/1000W Titanium Power Supply W/PMbus W76xL336xH40mm
Power Efficiency
  • 96%
Total Output Power and Input
  • 1000W with Input 100 - 127Vac
  • 1200W with Input 200 - 240Vac
  • 1200W with Input 200 - 240Vdc
AC Input Frequency
  • 50-60Hz
Dimensions (L x W x H)
  • 336 x 76 x 40 mm
Output Type
  • Backplanes (gold finger)
+12V
  • Max: 83A (100Vac - 127Vac)
  • Max: 100A (200Vac - 240Vac)
  • Max: 100A (200 - 240)
+5Vsb
  • Max: 4A / Min: 0A
Power Distributor
  • PDB-PT826-S8824
  • O/P: 12V/135A
  • +5V Max: 40A
  • +3.3V Max: 24A
  • -12V Max: 0.6A
Certification
  • Titanium Certified  Titanium Certified

Regulatory (Power Supply)

Power Supply Safety / EMC
  • BSMI
  • CCC
  • CE/EMC
  • FCC class A
  • UL/CB
  • UL/CUL
Bahias Fixed : 2
Bahias Hot-Swap : 9 - 24
Chasis Form Factor : 2U
Form Factor : 3.5''   2.5''
Power Supply : > 920W
